Various pinball PCB repair videos made mostly to show "proof of repair" for my clients. Some "how to" videos are linked the the PinWiki at www.PinWiki.com
Videos on YouTube31 new in 90 days · latest Nov 2
Various pinball PCB repair videos made mostly to show "proof of repair" for my clients.
Hibler repairs and bench-tests a WPC95 power driver board headed for a Tales of the Arabian Nights machine.
Nov 2
Hibler repairs a Williams System 11A MPU board with bent pins, a shorted Q9, and a missing Q50 for a Taxi machine.
Oct 31
Hibler repairs a myPinballs Gottlieb System 80B MPU board with a dead 74HCT00 and switch matrix short.
Oct 21
Hibler repairs a flaky Gottlieb Monte Carlo by replacing its MPU daughter card and adding free play ROMs and a CR2032 battery.
Oct 20
Chris Hibler troubleshoots and resolves a Williams High Speed MPU lamp matrix fault, documenting the diagnostic path.
Oct 12
Hibler repairs a Gottlieb Arena MPU board with solder bridges and a faulty reset circuit, restoring it to working order.
Oct 11
Hibler shows a leaked 100uF cap and severed trace on a Twilight Zone WPC opto board during a repair.
Oct 11
Hibler repairs an IC Night Moves System 80B MPU lockup, isolating a stuck IRQ fault with a Quick Scan 80 and a tip from Jerry Claus.
Oct 2
Hibler repairs and tests a Gottlieb System 80B Gold Wings MPU and driver board, fixing resets and hacks.
Oct 1
Hibler repairs a botched Gottlieb Arena System 80B MPU board, finding solder bridges via continuity raking.
Sep 28
Hibler repairs and tests a Gottlieb Haunted House System 80 board set, detailing mods and bench test procedures.
Sep 26
Hibler repairs a failed PCM1755DBQ sound chip on a Stern Star Trek SAM MPU board and bench-tests it.
Sep 25
Chris Hibler repairs a Stern SAM power driver board by replacing a failed VN5160 lamp-column driver chip.
Sep 19
Repair walkthrough of a Williams Hurricane power driver, MPU, and preDCS sound board with Riggore-style upgrades.
Sep 18
Hibler completes a functional checkout of a repaired White Star I/O driver board with upgraded fets and tests passing.
Sep 18
Hibler repairs an alkaline-corroded WPC95 MPU board and salvages a broken ASIC via a grind-and-scab fix.
Sep 13
Hibler's bench routine for fixing and preventively servicing a Williams WPC power driver board.
Sep 13
Hibler repairs a resetting Williams Black Rose MPU and driver board pair, fixing an open cap, corrosion and a torn trace.
Sep 11
Chris Hibler repairs corrosion damage on a modified Stern Elvis WhiteStar MPU and DMD controller board.
Sep 2
Hibler repairs a Gottlieb Hollywood Heat MPU freeze: corrosion cleanup, trace rebuilds, new reset circuit, and a trough switch fix.
Aug 26
