On Location
Pit Stop, released by Williams Electronic Games Inc. in 1968, is an electro-mechanical pinball machine designed by Norm Clark with artwork by Christian Marche. With a car racing theme, this two-player game features a unique lap-scoring system where players accumulate laps using separate two-reel displays.
On the floor at 2 locations
Converts 10¢/25¢ or 5¢ play to 2 plays per 25¢
129 KB
Drawings of coin trip and switch assemblies with part lists
42 KB
Service suggestions and troubleshooting, no schematics
1.1 MB
Fold-out with wire color code and switch symbol keys
2.0 MB
