"Dragonfist" is a pinball machine released by Stern Electronics in November 1981. It features a martial arts theme with two flippers, no ramps, and no multiball. The machine is built on the Stern M-200 MPU system, with a total production of only 302 units, making it quite rare. Designed by Joe Joos Jr. with artwork by Doug Watson.
On the floor at 7 locations
MPU switch adjustment tables for game settings
8.5 MB
Playfield scoring by switch and fold-out lamp schematic
19.6 MB
Solenoid and lamp driver boards with wire-color chart
2.3 MB
